| CPU | | • Intel® Core™ i7-6700HQ processor
( 14nm, 2.6GHz, DDR3L-1600MHz, 8MB Smart cache, TDP: 45W) |
|
| | Core Logic | | | •Mobile Intel® HM170 Express Chipset |
|
| | Display | | | 17.3”(43.94cm) FullHD (1920x1080) 16:9 panel |
|
| | Memory | | • Dual channel DDR3L
• Two 204 pins SODIMM sockets, support DDR3L 1600MHz
(Real operation frequency depends on processor)
• Expandable memory up to 16GB, depends on 2GB /4GB/8GB SODIMM module |
|
| | Video Controller | | • Intel® HD Graphics 530
- Dynamic frequency
- Intel Dynamic Video Memory Technology
- Microsoft DirectX® 12 compatible
• NVIDIA® GeForce 940M (N16S-GT)
- 2GB gDDR3 Video RAM
- Support PCIe x4
- Microsoft DirectX® 12 compatible
- NVIDIA PhysX™
- GeForce CUDA™ technology
• Microsoft Hybrid Graphics
|
|
| | Storage | | • One changeable 2.5”9.5 mm(H) / 7mm(H) HDD/SSD, SATA interface
• (Factory Option) One changeable 12.7mm(H) Super Multi ODD, SATA interface
• (Factory Option) One M.2 2280 SSD, SATA interface or one M.2 2280 SSD, PCIe
Gen3 x4 interface
• (Factory Option) One changeable Caddy Bay 12.7mm(H) ODD, 2.5”,9.5mm(H)
HDD/SSD, SATA interface |
|
| | Keyboard | | • Italian layout full size isolated keyboard with numeric pad
• Built in click pad with multi-gesture and scrolling function
• (Factory Option) Multi languages illuminated full size keyboard with numeric pad |
|
| | Sound System | | • High Definition Audio
• Built in microphone
• Built in two speakers
• Sound Blaster™ Cinema 2 |
|
| | I/O Ports | | • 1 x USB 2.0 port
• 3 x USB 3.0 ports
• 1 x external VGA port
• 1 x HDMITM output port (with HDCP) .png)
• 1 x Headphone jack
• 1 x Microphone jack
• 1 x RJ-45 LAN port
• 1 x DC-in jack |
|
| | Card Reader | | • 9-in-1 card reader
- MMC / RSMMC
- SD / mini SD / SDHC / SDXC
- MS / MS Pro / MS Duo |
|
| | Slots | | • Two M.2 Card slots
- 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface
- 2nd for SSD M.2 2280 Card with SATA / PCIe Gen3 x4 interface |
|
| | Communication | | • Built-in 10/100/1000Mb Base-TX Ethernet LAN
• 1.0M HD / 2.0M FHD video camera |
|
| | Power | | • Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19V, 4.74A, 90W
• (Factory Option)Removable 6 cells Smart Lithium-Ion battery pack, 62.16WH
• Battery life : 310 minutes |
|
| | Security | | • Kensington® Lock
• Intel® PTT for system without Hardware TPM
• (Factory Option) TPM 2.0 |
|
| | Certificate | | • Windows®10 (64-bit) Logo
• HDMITM Logo |
|
| | Dimension | | • 413(W)x272.8(D)x36.4(H)mm
• 3.1kg |
|
Memoria, hard disk, masterizzatore, modulo wireless e sistema operativo non inclusi, per sceglierli potete utilizzare il nostro configuratore
oppure scriverci a vendite@syspack.com indicandoci le vostre preferenze.
