| CPU + Chipset | | ?Intel Core i5-6200U processor
(14nm, 2.3GHz, DDR3L-1600MHz, 3MB smart cache, TDP: 15W) |
|
| Display | | | ?14.0 (35.56cm) FullHD IPS (1920X1080) 16:9 panel, 3.0mm |
|
| Memory | | ?Dual channel DDR3L
?Two 204 pins SODIMM sockets, support DDR3L 1600MHz (Real operation frequency depends on processor)
?Expandable memory up to 16GB, depends on 2GB/4GB/8GB SODIMM module |
|
| Video Controller | | ?Intel HD Graphics 520
- Dynamic frequency
- Intel Dynamic Video Memory Technology
- Microsoft DirectX® 12 compatible |
|
| Storage | | ??One changeable 2.5 7.0mm(H) HDD / SSD, SATA interface
?(Factory Option) One M.2 SSD 2280, SATA/PCIE Gen3x4 interface |
|
| Keyboard | | ?Italian layout A4 size isolated keyboard
?Built in touch pad with multi-gesture and scrolling function |
|
| Sound System | | ??High Definition Audio
?Built in microphone
?(Factory option) Built in array microphone
?Built in two speakers |
|
| I/O Ports | | ?1 x USB 2.0 port
?2 x USB 3.0 ports
?1 x external VGA port
?1 x HDMI output port (with HDCP).png)
?1 x Headphone jack
?1 x Microphone jack
?1 x RJ-45 LAN port
?1 x DC-in jack |
|
| Card Reader | | ?6-in-1 Card reader
- MMC / RSMMC
- SD / mini SD / SDHC / SDXC |
|
| Slots | | ?Three M.2 card slot
- 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface (A Key)
- 2nd for M.2 SSD 2280 Card with SATA / PCIE Gen3x4 interface
- (Factory Option)3rd for LTE or UMTS/HSPA+ M.2 3042 Card with USB interface (B Key) |
|
| Communication | | ?Built in 10/100/1000Mb Base-TX Ethernet LAN
?(Factory option) LTE M.2 module 3042
? 1.0M HD video camera |
|
| Power | | ?Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19V 2.1A, 40W
?Removable 4 cells Smart Lithium-Ion battery pack, 32WH
?Battery life: 290 minutes |
|
| Security | | ?Kensington Lock
?Intel PTT for system without Hardware TPM
?(Factory option) TPM 2.0 |
|
| Certificate | | ?Windows 10 (64-bit)
?Windows 10 Logo
?HDMITM Logo |
|
| Dimension | | 340(W) x 243.5(D) x 22.2 (H)mm (Height excluded battery area)
1.8kg
|
|
Memoria, hard disk, modulo wireless e sistema operativo non inclusi, per sceglierli potete utilizzare il nostro configuratore
oppure scriverci a vendite@syspack.com indicandoci le vostre preferenze.
