| CPU + Chipset | | • Intel® Core™ i7-6500U processor
(14nm, 2.5GHz, DDR3L-1600MHz, 4MB smart cache, TDP: 15W) |
|
| | Display | | | • 14.0” (35.56cm) FullHD IPS (1920X1080) 16:9 panel, 3.0mm |
|
| | Memory | | • Dual channel DDR3L
• Two 204 pins SODIMM sockets, support DDR3L 1600MHz (Real operation frequency depends on processor)
• Expandable memory up to 16GB, depends on 2GB/4GB/8GB SODIMM module |
|
| | Video Controller | | • Intel® HD Graphics 520
- Dynamic frequency
- Intel Dynamic Video Memory Technology
- Microsoft DirectX® 12 compatible |
|
| | Storage | | • One changeable 2.5” 7.0mm(H) HDD / SSD, SATA interface
• (Factory Option) One M.2 SSD 2280, SATA/PCIE Gen3x4 interface |
|
| | Keyboard | | • Italian layout A4 size isolated keyboard
• Built in touch pad with multi-gesture and scrolling function |
|
| | Sound System | | • High Definition Audio
• Built in microphone
• (Factory option) Built in array microphone
• Built in two speakers |
|
| | I/O Ports | | • 1 x USB 2.0 port
• 2 x USB 3.0 ports
• 1 x external VGA port
• 1 x HDMI output port (with HDCP).png)
• 1 x Headphone jack
• 1 x Microphone jack
• 1 x RJ-45 LAN port
• 1 x DC-in jack |
|
| | Card Reader | | • 6-in-1 Card reader
- MMC / RSMMC
- SD / mini SD / SDHC / SDXC |
|
| | Slots | | • Three M.2 card slot
- 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface (A Key)
- 2nd for M.2 SSD 2280 Card with SATA / PCIE Gen3x4 interface
- (Factory Option)3rd for LTE or UMTS/HSPA+ M.2 3042 Card with USB interface (B Key) |
|
| | Communication | | • Built in 10/100/1000Mb Base-TX Ethernet LAN
• (Factory option) LTE M.2 module 3042
• 1.0M HD video camera |
|
| | Power | | • Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19V 2.1A, 40W
• Removable 4 cells Smart Lithium-Ion battery pack, 32WH
• Battery life: 290 minutes |
|
| | Security | | • Kensington® Lock
• Intel® PTT for system without Hardware TPM
• (Factory option) TPM 2.0 |
|
| | Certificate | | • Windows® 10 (64-bit)
• Windows® 10 Logo
• HDMITM Logo |
|
| | Dimension | | • 340(W) x 243.5(D) x 22.2 (H)mm (Height excluded battery area)
• 1.8kg |
|
Memoria, hard disk, modulo wireless e sistema operativo non inclusi, per sceglierli potete utilizzare il nostro configuratore
oppure scriverci a vendite@syspack.com indicandoci le vostre preferenze.
