| | CPU | | • Intel® Core™ i7-6700HQ processor
(14nm, 2.6GHz, DDR3L-1600MHz, 8MB Smart cache, TDP: 45W) |
|
| | Core Logic | | | • Mobile Intel® HM170 Express Chipset |
|
| | Display | | | • 15.6”(39.62cm) FHD IPS (1920x1080), 16:9 panel,Matte |
|
| | Memory | | • Dual channel DDR3L
• Two 204 pins SODIMM sockets, support DDR3L 1600 MHz
(Real operation frequency depends on processor)
• Expandable memory up to 16GB, depends on 2GB/4GB/8GB SODIMM module |
|
| | Video Controller | | • Intel® HD Graphics 530
- Dynamic frequency
- Intel Dynamic Video Memory Technology
- Microsoft DirectX® 12 compatible
• NVIDIA® GeForce 940MX (N16S-GTR)
- 2GB GDDR5 Video RAM
- Support PCIe x4
- Microsoft DirectX® 12 compatible
- NVIDIA PhysX®
- GeForce CUDA™ technology
• Microsoft Hybrid Graphics
|
|
| | Storage | | • One changeable 2.5" 7mm(H) HDD / SSD, SATA3 interface
• (Factory Option) Two M.2 2280 SSD, SATA interface (RAID 0/1) or
One M.2 2280 SSD, PCIe Gen3x4 interface |
|
| | Keyboard | | • Italian full size isolated illuminated keyboard with numeric pad
• Built in touch pad with multi-gesture and scrolling function |
|
| | Sound System | | • High Definition Audio
• Built in array microphone
• Built in two speakers
• S/PDIF digital output
• Sound Blaster™ Cinema 2 |
|
| | I/O Ports | | • 3 x USB 3.0 (USB 3.1 Gen 1) ports
• 1 x USB 2.0 ports
• 1 x Mini Display port 1.2
• 1 x HDMITM output port (with HDCP)
• 1 x external VGA port
• 1 x Headphone jack
• 1 x Microphone jack
• 1 x S/PDIF output jack
• 1 x RJ-45 LAN port
• 1 x DC-in jack |
|
| | Card Reader | | • 6-in-1 Push-Push Card reader
- MMC / RSMMC
- SD / mini SD / SDHC / SDXC |
|
| | Slots | | • Three M.2 card slots
-1st for WLAN Combo M.2 2230 Card with PCIe and USB interface (A key)
-2nd for SSD M.2 2280 Card with SATA / PCIe Gen3x4 interface (M key)
-3rd for SSD M.2 2280 Card with SATA Interface (B key)
-(Factory Option) 3rd for LTE or UMTS/HSPA+ M.2 3042 Card with USB interface (B key) |
|
| | Communication | | • Built-in 10/100/1000Mb Base-TX Ethernet LAN
• 1.0M HD / 2.0M FHD video camera |
|
| | Power | | • Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19V, 4.74A, 90W
• Embedded 3 cells Prismatic battery pack, 48WH
• Battery life: 300 minutes (with UMA mode, 48WH Battery) |
|
| | Security | | • Kensington® Lock
• Intel® PTT for system without hardware TPM
• (Factory Option) TPM2.0 |
|
| | Certificate | | • Windows® 10 Logo
• HDMITM Logo |
|
| | Dimension | | • 385 (W) x 269 (D) x 23.9 (H) mm
• 2.1 kg, including Barebone and 48 WH Battery |
|
