COOLER MASTER - MasterBox NR200 Black Mini-ITX SFX

SIZE Mini ITX

COLOR Black

MATERIALS Steel, Plastic, Mesh

DIMENSIONS (L X W X H)376 x 185 x 292mm incl. Protrusions, 360 x 185 x 274mm excl. Protrusions

VOLUME (EXLC. PROTRUSIONS)18.25L

MOTHERBOARD SUPPORT Mini DTX, Mini ITX, Max MB size: 244 x 226mm (L x H)

EXPANSION SLOTS 3

3.5" DRIVE BAYS 1 (Max. 2)

2.5" / 3.5" DRIVE BAYS (COMBO)1

2.5" DRIVE BAYS 2 (Max. 3)

I/O PANEL 2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)

PRE-INSTALLED FANS - TOP 2x 120mm 650-1800RPM PWM (SickleFlow)

FAN SUPPORT - TOP 2x 120mm

FAN SUPPORT - REAR 1x 92mm

FAN SUPPORT - BOTTOM 2x 120mm (recommended slim fans for GPUs wider than 2.5 PCI slots)

FAN SUPPORT - SIDE 2x 120/140mm

RADIATOR SUPPORT - REAR 92mm (not compatible with vertical GPU installation)

RADIATOR SUPPORT - BOTTOM 120mm, 240mm, (recommended for custom loops only)

RADIATOR SUPPORT - SIDE 120mm, 140mm, 240mm, 280mm, (max width 141mm, not compatible with vertical GPU installation)

CLEARANCE - CPU COOLER 76mm (GPU in vertical position), 153mm (tempered glass side panel), 155mm (vented steel side panel)

CLEARANCE - PSU 130mm

CLEARANCE - GFX L: 330mm (incl. power connector), H: 156mm (incl. power connector), W: 60mm (triple slot)

DUST FILTERS Top, Bottom, Left side, Right side

POWER SUPPLY SUPPORT SFX, SFX-L

WEIGHT 5.1 kg

ACCESSORIES 1x PCIe 3.0 x16 riser cable

NOTE Single slot water-cooler GPUs or vertically mounted GPUs are recommended when using bottom radiator position, This product is only compatible for devices that support the PCI-E 3.0 specification. If you use this product with a motherboard that supports PCI-E 4.0, please enter into BIOS option and select PCI-E 3.0 before installation.
